โปรเซสเซอร์เสียงดิจิตอล D6575

Model

D6575

Output Channel Jacks

5.1 XLR male (a pair of main channel, a pair of surround, center, sub) and optical fiber output

Input Channel Jacks

1 in 4 music signal (RCA input, optional fiber input, coaxial input), 5 in three groups mic input hole

Input Impedance

Unbalance: 20KΩ

Output Impedance

Balance: 100Ω

PC Port

1 USB (front panel)

Remote Control

S terminal

CMRR

＞70dB(1KHz)

Input Range

≤+5dBu

Frequency Response

20Hz-20KHz(-0.5dB)

S/N R

≥95dB@1KHz 0dBu

THD

＜0.03%OUTPUT=0dBu/1KHz

Crosstalk of Channels

＞110dB(1KHz)

Functions of Input Channels

Input Mute

Each channel has independent mute control.

Input Delay

Each input channel has a separate delay control, adjustable range of 0-30ms, less than 10ms, step away from the 0.1ms; greater than 10ms, step away from the 1ms

Input Polarity

+/-

Input Select

MUSIC AUX/VOD/Coaxial/Optical, AUX/VOD can select 0dB or 6dB

Input EQ

Set a 9-band EQ for Music and MIC (EQ1 low, EQ9 high, others with PEQ): center frequency: 20Hz-20KHz, bandwidth: 0.01oct-3oct, with a step size of 0.01oct, gain: -30dB-+15dB, with a step size of 0.1dB, default frequency: EQ1 40Hz, EQ2 80Hz, EQ3 160Hz, EQ4 317Hz, EQ5 632Hz, EQ6 1261Hz, EQ7 2515Hz, EQ8 5018Hz, EQ9 10KHz. In addition to the 9-band EQ, additional high-pass and low-pass filters with fixed slopes are added.

Input Volume

Each input volume range: 0-100%, step@1%

Limiter

Each input channel has a limiter. Threshold: -30dBu~+20dBu  step: 0.1dBu

Feedback

4 level

Functions of Output Channels

Output Mute

Each channel has independent mute control.

Output Polarity

In-phase (+/+) or reversed phase (+/-)

Output EQ

Set a 7-band EQ for each output channel (low, high, PEQ): center frequency: 20Hz-20KHz, bandwidth: 0.01oct-3oct, with a step size of 0.01oct, gain: -30dB-+15dB, with a step size of 0.1dB, default frequency: EQ1 47Hz, EQ2 112Hz, EQ3 266Hz, EQ4 631Hz, EQ5 1495Hz, EQ6 3544Hz, EQ7 8399Hz.

Output Gain

Each output volume range: 0-100%, step@1%

Output Delay

Each output channel has a separate delay control, adjustable range of 0-60ms, less than 10ms, step away from the 0.1ms; greater than 10ms, step away from the 1ms

X-OVER

Each output channel can be independently set as LPF or HPF. These parameters can be adjusted. Filter type: Linkwitz-Riley; Bessel; Butterworth. The crossover frequency: 20Hz~20KHz, slope: 12db/oct; 18db/oct; 24db/oct; 30db/oct; 36db/oct; 42db/oct; 48db/oct.

Limiter

Each output channel has a limiter, threshold: -30dBu~+20dBu  step: 0.1dBu

Effect

3 band of EQ, HC/LC, effect ratio can be adjusted

Processor

96KHz sampling frequency, 32-bit floating-point DSP, 24-bit A/D and D/A conversion

Display

The distinguishing rate for 144*32 characters LCD screen

Power

≤30W

Power Supply

AC110V/220V  50/60Hz

Product Dimensions (W×D×H)

482×228×44mm

Net Weight

4.5kg

Shipping Dimensions (W×D×H)

1PC: 555×325×98mm/0.0177m³  6PCS: 573×337×615mm/0.1188m³

Gross Weight

1PC: 5(kg)  6PCS: 31.5(kg)
